13.5kVA PETROL GENERATOR

The Maxwatt® MX13000AS 2-wire auto – start petrol generator has been designed to provide backup power for off-grid solar power systems. Manufactured to Euro V standard emission controls, ensuring clean power.



  • It has a pre-installed 2-wire automatic control system. This generator can automatically provide backup to recharge the storage battery and feed in power to supply the load.
  • High-output and fuel-efficient 4-stroke overhead valve 688cc petrol engine.
  • Manufactured to Euro V standard emission controls, ensuring clean power.
  • The Electrical Safety RCD safety switch provides WH&S mandated protection against electric shock, featuring a 240-Volt AC, 2 x 15-Amp Outlets and 1 x 32 Amp with an IP66-rated cover and electrical sockets.
  • Frame Terminal for earthing.
  • Superior quality Senci copper Pure Sine Wave Alternator with a THD < 5% -therefore ensuring stable power, perfect for all sensitive equipment.
  • The MASSIVE 45L Fuel Tank is the largest in its class, which provides extended run time with an integrated gauge and strainer.
  • The running time at 10 hrs at 50% load and 6 hours at 100% load is perfect for the job site.
  • Large Muffler Design to Reduce Noise.
  • Heavy-duty 32mm steel roll frame.
  • Never-Flat wheels and Lifting handles allow you to move it about with ease and safety.
  • Effortless Starting, electric starting at the turn of a switch.
  • Simple, easy to use, with limited assembly required. Add oil and fuel.
  • 2-year warranty to give you peace of mind.

Description

The Maxwatt® MX13000AS 2 wire auto start petrol generator has been designed to provide back up power for off grid solar power systems. It has a pre-installed 2 wire automatic control system. This generator can automatically provide back up to recharge the storage battery and feed in power to supply the load.

The Maxwatt range of generators have been manufactured using only high-quality components and designed to last in the toughest conditions.

It features a powerful, economical, quality 688cc V twin petrol engine, perfect for powering tools, domestic appliances as well as sensitive electronics as it offers high efficiency, stable voltage and increased output.

This generator produces 10000-watts of continuous power, and 11000-watts of maximum power at approximately 82dB, which means that you will be able to power more electrical equipment and is the perfect power solution for the job site, camp site or if you are just using it for backup power at home or office.

This easy to start generator boasts a huge 45 litre long range fuel tank provides up to 10 hours of run time at 50% load or 6 hours at 100% load.

This generator is fitted with an easy to start electric start starting ignition, never run flat heavy-duty wheels and U-shaped handle for easy transportation.

It is equipped with 2 x 15 Amp; 1 x 32 Amp 240 Volt IP66 socket outlets and an RCD safety switch which enables you to safely run two appliances at once.

Backed with a two-year warranty the Maxwatt generator is designed and manufactured to provide you with peace of mind and the power when you need it!

Additional information

Starting Watts

11000W

Running Watts

10000W

Starting Amps at 240V

45.8A

Running Amps at 240V

43.8A

Voltage

240V

Frequency

50Hz

Outlets

2 x 15A IP66, 1 x 32A IP66

Covered Outlets

2-Wire Connect

Covered Circuit Breakers

15A Circuit Protector, 32A Circuit Protector, 42A Circuit Breaker

Fuel Running Time at 50% Load

10 hrs

Fuel Running Time at 100% Load

6 hrs

Noise Level

96dB

Inverter

SENCI

Voltmeter

Yes

Automatic Voltage Regulation

Yes

Battery

12V 36Ah Lead Acid

Start Type

Electric, 2 Wire Auto Start

Engine Brand

Maxwatt

Engine Size

688cc

Engine Type

Double Cylinder

Engine Speed

Constant 3600 rpm

Fuel Type

Petrol Unleaded

Fuel Gauge

Mechanical Oil Gauge

Fuel Tank Capacity

45L

Fuel Tank Material

Metal

Engine Oil Type

10W-30

Engine Oil Capacity

1.5L

Engine Oil Included

Yes

Low Oil Shut-Off

Yes

Wheels

Yes

Wheel Type

Rubber

Wheel Diameter

254mm

Euro V certified

Yes

Dimensions (LxWxH)

730 x 600 x 780mm

Net Weight

167kg

Download Brochure

Parts Catalogue

Dimensions

Dimensions Box

Length 755
Width 625
Height 790
Weight 160kg

Dimensions Product

Length 730
Width 600
Height 780
Weight 150kg
